Film Blowing Flexo Printing Connect-line

Product Description:

USE:
It is applied to blowing plastic films like low density polytene(LDPE), high density polytene(HDPE) and linear low density polytene(LLDPE), etc.It is widely applied to packing foodstuff, clothing rubbish bags, vest ones, etc.in the civil and industries sectors.

Characteristics:
The unit integrated film-blowing & printing that was designed by the company can save labor force, workshop rooms, and improve the quality of products and economic results.

Main Technical Variables:

Model	SJ-45-YT2600	SJ-55-YT2800	SJ-60-YT21000
Suitable material	LDPE HDPE LLEPE	LDPE HDPE LLEPE	LDPE HDPE LLEPE
Screw Diameter	45mm	55mm	60mm
Screw i/d length	L/D28:1	L/D28:1	L/D28:1
Blowing film driving motor	11kw	15kw	18.5kw
Main Output	35kg/h	50kg/h	70kg/h
Die size	¢60-¢80mm	¢80-¢130mm	¢80-¢160mm
Width of blosing film	600mm	800mm	1000mm
Thickness of blowing film	0.008-0.10mm	0.008-0.10mm	0.008-0.10mm
length Range of Printing	191-1200mm	191-1200mm	191-1200mm
Printing Width	560mm	760mm	960mm
Weight of Machine	3800kg	4200kg	5000kg
Overall Dimensions	6000x2400x4000mm	6200x2600x4300mm	6400x2800x4800mm
