Lifting HDPE-LDPE Film Blowing Machine

Product Description:

Characteristics:

This film blowing machine is used for blowing the various plastic film of low density polyethylene(LDPE), high density polythylene(HDPE)and linear low density polyet-hylene(LLDPE)etc,Which are widely used for packing food,fruit, garments, textile, garbage bag and vest bag other civil and industrial products, etc and for vest bag.

Main Technical Variables:

Model type	SJ-45-500mm	SJ-50-600mm
Diameter of Screw Stem	45mm	50mm
Major Diameter Ratio of Screw Stem	28:1	28:1
Thickness of Products	0.004-0.08mm	0.004-0.08mm
Folding Width of Products	200-500mm	200-600mm
Main Motor Power	7.5kw	11kw
Heating Power	12kw	13kw
Rational Speed of Screw Stem	10-120rpm	10-120rpm
Output	20-30kg/h	20-35kg/h
Weight of Machine	1800kg	1900kg
Overall Dimensions	6000x2000x3200mm	6200x2100x3200mm
