Plastic Grinding Milling Granulator

Product Description:

Characteristics:

The machine adopts Japanese design principles, employs the principles of grinding rapidly, agitating continuously, milling and fractioning to be heated with multi-knives and cooling and contracting. It produces granules from waste materials and angle materials such as the plastic films, filament, ribbons, pieces, soft plastic pipes, foaming materials, and degrading materials, and puts then into reproduction .It is the latest ideal granulating equipment to recycle plastics and reproduce.

Main Functions:

1.Recycle the waste materials and leftover bits and pieces of various flexible plastic films, bags, filament, ribbons, pieces, and pipes such as polyvinyl chloride, polyethylene of higher density, and linear polyethylene of lower density, and put them into reproduction.

2.Recycle and reproduce the grinding and granulating of degrading plastic films and angle materials.

3.Grind chemical fiber waste materials, and process the waste filament that has been put into reproductions.

4.The machine is applied in many respects. It can be substitute for blending machine or dryer.

Main Technical Variables:

Capacity of Barrel	150L	100L
Output Capacity	60-80kg/h	30-60kg/h
Main Motor Power	18kw	15kw
Water Adding Device	125w	125w
Heating Power	1.5kw	1.5kw
Rotary Speed of Main Shaft	660r/min	660r/min
Overall Dimensions	1500×700×1400mm	1300×600×1300mm
