Flexography Printing Machine

Two-color Flexography Printing Machine

Product Description:

Use:
This machine is suitable for printing such packing materials as polyethylene,polypropylene plastic bag,cellophane and roll paper,etc.And it is a kind of ideal printing equipment for producing paper packing bag for fod ,supermarket carry bag ,vest bag and clothes bag,etc.

Characteristics:
1.Easy operation,flexible starting,accurate colour regicter.

2.The meter counter can set printing quantity according to the requirements.Stop the machine automatically at the set quantity or when the material is cut off.

3.Lift and lower the printing plate cylinder manually,it will automatically stir the printing ink after lifting.

4. The printing ink is spread by the knurled cylinder with ecen ink colour.

5.Reliable drying system coordinated with high-speed rtation,it will automatically bueak circuit it when the machine stops.

6.360 continuous and adjustable register device.

7.The imported fuequency control of motor speed adapts to different printing speeds,

8.There are Inching/Stopping buttons on the plate roller base and material rolling rack soas to make it easy operate the machine when the plate is installed.

Main Technical Variables:

Model	YT-600/2COLORS	YT-800/2COLORS	YT-1000/2COLORS
Max.width of Printing	560mm	760mm	960mm
Printing Length	191-914mm	191-914mm	191-914mm
Max.width of Base Material	450mm	450mm	450mm
Printing Speed	5-50m/min	5-50m/min	5-50m/min
Plate Thickness(Both side adhesive tape included)	2.38mm	2.38mm	2.38mm
Total Power	8kw	10kw	12kw
Weight of Machine	1800kg	2000kg	2200kg
Overall Dimensions	2300×1860×2145mm	2300×2060×2145mm	2300×2260×2145mm
